คำอธิบาย
Industrial AC Servo Motor 400W
- Rated Power Output 400W
- Frame Flange Size 60x60mm
- Shaft Diameter 14mm
- Rated Current 2.4A
- Maximum instantaneous Current 8.4A
- Rated revolving speed 3000r/min
- Maximum revolving speed 6000r/min
- Rated torque (N-m) 1.27Nm
- Maximum torque (N-m) 4.45
- Mounting Hole Diameter M5x12mm or more Hexagon socket
- Protection Class IP65
- RoHS, FCC
ในชุดประกอบด้วย
- 1Set x AC Servo Motor ECM-E3M-CM0604RSE
- 1Set x AC Servo Driver ASD-E3-0421-L
- 1Set x 3M Cable
Motor ECM-E3M-CM06 04 RSE
Dimension
AC Servo Driver ASD-E3-0421-L
Wiring 1Phase
Instruction Manual
- ECM-E3M-CM0604RSE
- AC Servo Drive ASD-E3-0421-L Operation Manual Language Simplified Chinese
- https://filecenter.deltaww.com/Products/download/06/060201/Manual/DELTA_IA-ASD_ASDA-E3_UM_EN_20230621.pdf
- Manual https://drive.google.com/drive/folders/1wGKNkEY85kLxWtkCyP6Mmn0Y1K5CeKOr?usp=sharing
